Cyclone IV E Series FPGA Core Board

1.Product Highlights

The Altera Cyclone IV EP4CE75F23I7N FPGA Development Board is a high-performance, low-power single-board computer designed for embedded applications in industrial control, communication equipment, and consumer electronics. Built around the Altera Cyclone IV E series FPGA — featuring 74,208 logic elements and 2.8Mbit embedded RAM — this board delivers smooth signal processing, multi-protocol conversion, and robust peripheral connectivity. Its compact circular PCB layout integrates essential interfaces including JTAG, AS configuration, power management, and I/O expansion areas. This board is ideal for FPGA learning and mid-to-high-end project development.

2. Technical Specifications

3. Applications

 Industrial PLC multi-axis motion control

 Communication equipment multi-protocol conversion

 Consumer electronics display interface bridging

 Image preprocessing and signal processing
